5.6 Ton Crawler Sugar Cane Harvesting Machine
Key Specifications / Features
Model No.: WE-230811-SH-02
Hits: 5
Meet the Crawler Sugar Cane Harvesting Machine: a robust solution meticulously crafted for effective sugarcane harvesting. This machine boasts a 95.6 KW rated power engine and an intelligent automatic rubber crawler undercarriage, ensuring seamless operation at a maximum walking speed of 5 km/h. With an operating weight of 5600 kg, coupled with advanced features like GPS and hydraulic guide control, it guarantees a productivity rate of 2.9 kg/s while upholding stability even on inclines of up to 18°.
Request a quote
Tags
Detail Information
Crawler Sugar Cane Harvesting Machine
Operating Weight: 5600 kg, 5.6 Ton
Rated Power: 95.6 KW
Rated Speed: 2200 r/min
Productivity: 2.9 kg/s
Operation Model: GPS, Hydraulic Guide Control
Undercarriage Style: Intelligent Automatic Rubber Crawler
Gradeability: ≤ 18°
Max. Walking Speed: 5 km/h
| SUGAR CANE HARVESTER SPECIFICATIONS | |
| TECHNICAL PARAMETERS | |
| Engine | DongFangHong |
| Rated Power | 95.6KW |
| Rated Speed | 2200r/min |
| operation model | GPS,hydraulic guide control |
| Undercarriage Style | intelligent automatic rubber crawler |
| (Length×Width×Height) | 6000×1900×2800mm |
| Machine Weight | 5600kg |
| Track | 1150mm |
| Wheelbase | 1600mm |
| Productivity | 2.9kg/s |
| Total Loss of Combine(%) | ≤5 |
| Breakage Rate(%) | ≤10 |
| Dirt Percentage(%) | ≤2-3 |
| Fqt Fuel Quantity | 23L/h |
| Grade Climbing Ability | ≤18° |
| Row Spacing for Harvest | ≥900mm |
| Max. Walking Speed | 5km/h |
| Hydraulic Tank Capacity | 300L |
| Fuel Tank Capacity | 190L |
