Key Specifications / Features
Presenting our Mini Rubber Chain Crawler Excavators–compact and versatile machines weighing 1600 kg (1.6 Ton). With a rated power range of 13.6 kw to 19 kw, these excavators deliver efficient performance. Equipped with a 790 mm tail swing radius, 0.04 m³ bucket volume, and impressive dimensions, they excel in various tasks. Achieve a Max Digging Reach of 2882 mm and navigate challenging terrains effortlessly with a Gradeability of < 30°.
- Model No.: WE-230811-ME-03
- Hits: 6
- Categories: Mini Excavators
- Tags: 1 Ton Excavator , Fully Hydaulic Excavators , Mini Digging Machines
Detail Information
Operating Weight: 1600 kg, 1.6 Ton
Rated Power: 13.6/19 kw
Tail Swing Radius: 790 mm
Volume of Bucket: 0.04 m³
Max Digging Reach: 2882 mm
Max Digging Depth: 1748 mm
Max Digging Height: 2587 mm
Max Dumping Height: 1892 mm
Gradeability: < 30 °
| SPECIFICATIONS | |
| RANGE OF OPERATION | |
| Boom length | 1735mm |
| Arm length | 815mm |
| Maximum Digging Reach | 3800mm |
| Maximum Digging Depth | 1900mm |
| Maximum Digging Height | 3335mm |
| Maximum Dumping Height | 2165mm |
| Back-end radius of gyration | 940mm |
| DIMENSION | |
| (Length*width*height) travel position | 2800*1000*2080mm |
| Wheel base | 750mm |
| Min ground clearance | 115mm |
| TECHNICAL PARAMETERS | |
| Machine weight | 1600kg |
| Rated Power | 13.6KW/19KW |
| Volume Of Bucket | 0.04m3 |
| Hydraulic system working pressure | 16Mpa |
| Swing speed | 15rpm |
| (High speed/low speed) | 0~2km/h |
| Max digging force of bucket | 9.6KN |
| Max digging force of arm | 8.5KN |
| Ground pressure | 2.3Kpa |
| Grade Climbing ability | <30° |
| Max digging force of arm | 8.5KN |
| Ground pressure | 2.3Kpa |
| Grade Climbing ability | <30 ° |
