Hydraulic Shearing Metal Machine for Demolition Equipment
Key Specifications / Features
Model no.: WE-231008-SCM-10
Hits: 2
Explore our hydraulic type shearing metal machine is equipped with a hydraulic automatic transmission for swift movement. It also offers enhanced stability thanks to the inclusion of double boom cylinders, making it a reliable choice for metal shearing tasks.
Request a quote
Tags
Detail Information
Range of operation | |
Boom length | 4500mm |
Arm length | 2200mm |
Angle of rotation of the shear | 360° |
Max.opening distance of the shear | 650mm |
Length of hydraulic shear blade | 2-2*185mm |
Max. cutting force (in middle of blade) | 350KN |
Max. lifting height of car pressing hand | 2000mm |
Max. distance of car pressing hand working | 5000mm |
Dimensions | |
(Length*width*height)Transport dimensions | 8000*2500*3550mm |
Axle base | 2850mm |
Track gauge | 1960mm |
Width of crawler | 500mm |
Ground clearance of counterweight | 940mm |
Min. ground clearance | 420mm |
Tech performance and specification | |
Angle of rotation | 360° |
Machine weight | 16500kg |
Engine model | YUCHAI(EuroⅢ) |
Rated power | 103kw |
Rated speed | 2200r/min |
Hydraulic system working pressure | 28Mpa |
Hydranlic system flow | 270L/min |
Variable piston pump | 2*63ml/r |
Max. traction force | 76.5KN |
Walking speed(high speed/low speed) | 5/2.9km/h |
Grade climbing ability | 70%/35° |
Full circle swinging time | 5.5s |
Swing overload pressure | 25Mpa |
Fuel quantity | ≥8L/h |
Fuel tank capacity | 200L |
Hydraulic oil tank capacity | 200L |
